To replace the default logo with your own corporate image using the Web Interface:
Access the gateway Embedded Web Server (see
1
Server).
In the URL field, append the suffix 'AdminPage' (note that it's case-sensitive) to the IP
2
address, for example, http://10.1.229.17/AdminPage.
Click Image Load to Device; the Image Download screen is displayed.
3
Image Download Screen
Figure 92
Click the Browse button in the Send Logo Image File from your computer to the
4
Device box. Navigate to the folder that contains the logo image file you want to load.
Click the Send File button; the file is sent to the device. When loading is complete, the
5
screen is automatically refreshed and the new logo image is displayed.
Note the appearance of the logo. If you want to modify the width of the logo (the default
6
width is 339 pixels), in the Logo Width field, enter the new width (in pixels) and click the
Set Logo Width button.
To save the image to flash memory so it is available after a power fail, see
7
Configuration.
The new logo appears on all Web Interface screens.
If you encounter any problem during the loading of the files, or you want to restore
the default images, click the Restore Default Images button.
