Using Parameter Tables

The gateway uses parameter tables to group related parameters of specific entities and
manage them together. These tables, similar to regular parameters, can be configured using
the ini file, Embedded Web Server, SNMP, and the like.
Tables are composed of lines and columns. Columns represent parameters' types. Lines
represent specific entities. The instances in each line are called line attributes. Lines in table
may represent (for example) a trunk, an NFS file system, list of timers for a given application,
and the like.
Table 58 and Table 59
Table 58 and
only and are not actually implemented in the gateway.
Example of Parameter Table - Remote Management Connections
Table 58
Index Fields:
1. Connection Number
Connection
User Name
Number
0 Admin
1 Gillian
2 David
Example of Parameter Table - Port-to-Port Connections
Table 59
Index Fields:
1. Source Ports
2. Destination IP
3. Destination Port
Source Port Destination IP
2020 10.4.1.50
2314 212.199.201.20
6010 10.3.3.41

Table Indices

Each line in a table must be unique. Therefore, each table defines one or more Index fields.
The combination of the Index fields determines the 'line-tag'. Each line-tag appears only
once.
In the example provided in
mark lines.
V7122 Gateway User Guide
provide useful examples for reference.
Table 59 are provided as examples for the purpose of illustration
User Password
Yellow9
Red5
Orange6
Destination Port Connection Name
2020
4050
6010
Table 58 there is only one Index field. This is the simplest way to
Time Connected
Permissions
(msec)
0 All
1266656 Read Only
0 Read Write
Application Type
ATM_TEST_EQ LAB_EQ
ATM_ITROP_LOOP LAB_EQ
REMOTE_MGMT MGMT
