3Com V7122 User Manual page 183

ini File Field Name
Web Parameter Name
UserName
[User Name]
Password
[Password]
Cnonce
[Cnonce]
IsRegisterNeeded
[Enable Registration]
RegistrarIP
[Registrar IP Address]
RegistrarName
[Registrar Name]
GWRegistrationName
[Gateway Registration Name]
AuthenticationMode
[Authentication Mode]
RegistrationTime
[Registration Time]
V7122 Gateway User Guide
Valid Range and Description
Username used for Registration and for Basic/Digest authentication
process with Proxy / Registrar.
Parameter doesn't have a default value (empty string).
Password used for Basic/Digest authentication process with Proxy /
Registrar.
The default is 'Default_Passwd'.
String used by the SIP Server and client to provide mutual authentication
(free format, that is, 'Cnonce = 0a4f113b').
The default is 'Default_Cnonce'.
0 = Gateway does not register to Proxy/Registrar (default).
1 = Gateway registers to Proxy/Registrar at power up.
The gateway sends a REGISTER request for each channel or
for the entire gateway (according to the parameter
AuthenticationMode).
IP address and optionally port number of Registrar server.
Enter the IP address in dotted format notation, for example
201.10.8.1:<5080>.
If not specified, the REGISTER request is sent to the primary
Proxy server (see 'Proxy IP address' parameter).
When port number is specified, DNS NAPTR/SRV queries are
not performed, even if DNSQueryType is set to 1or 2.
Registrar domain name.
If specified, the name is used as Request-URI in REGISTER messages.
If isn't specified (default), the Registrar IP address or Proxy name or Proxy
IP address is used instead.
Defines the user name that is used in From and To headers of REGISTER
messages.
If 'GWRegistrationName' isn't specified (default), the 'Username' parameter
is used instead.
This parameter is applicable only to a single gateway
registration (AuthenticationMode=1). When the gateway
registers each B-channel separately (AuthenticationMode=0),
the user name is set to the endpoint's phone number002E
0 (Per Endpoint) = Registration & Authentication separately for each B-
channel.
1 (Per Gateway) = Single Registration & Authentication for the gateway
(default).
Defines the time (in seconds) for which registration to a Proxy server is
valid. The value is used in the header 'Expires'. In addition, this parameter
defines the time interval between Keep-Alive messages when
EnableProxyKeepAlive = 2 (REGISTER).
Typically a value of 3600 should be assigned, for one hour registration.
The gateway resumes registration according to the parameter
RegistrationTimeDivider.
The default is 180 seconds.
183
