Branch Target Buffer

The Intel XScale
changing the flow of program execution. The core features a branch target buffer that provides the
instruction cache with the target address of branch type instructions. The branch target buffer is
implemented as a 128-entry, direct mapped cache.
This chapter is primarily for those optimizing their code for performance. An understanding of the
branch target buffer is needed in this case so that code can be scheduled to best utilize the
performance benefits of the branch target buffer.
5.1

Branch Target Buffer (BTB) Operation

The BTB stores the history of branches that have executed along with their targets.
shows an entry in the BTB, where the tag is the instruction address of a previously executed branch
and the data contains the target address of the previously executed branch along with two bits of
history information.
Figure 5-1.

BTB Entry

The BTB takes the current instruction address and checks to see if this address is a branch that was
previously seen. It uses bits [8:2] of the current address to read out the tag and then compares this
tag to bits [31:9,1] of the current instruction address. If the current instruction address matches the
tag in the cache and the history bits indicate that this branch is usually taken in the past, the BTB
uses the data (target address) as the next instruction address to send to the instruction cache.
Bit[1] of the instruction address is included in the tag comparison in order to support Thumb
execution. This organization means that two consecutive Thumb branch (B) instructions, with
instruction address bits[8:2] the same, will contend for the same BTB entry. Thumb also requires
31 bits for the branch target address. In ARM mode, bit[1] is zero.
Developer's Manual
®
core uses dynamic branch prediction to reduce the penalties associated with
TAG
Branch Address[31:9,1]
January, 2004
Intel XScale® Core Developer's Manual
Branch Target Buffer
DATA
Target Address[31:1]
5
Figure 5-1
History
Bits[1:0]
57
