DS1 Facilities
£ £
Delete Digits Procedure
Console Display/Instructions
1 Erase the current number of digits to delete ( n) .
n
2 Enter the new number of digits to delete ( n = 0 to 4 ).
3 Save your entry.
Select .
4 Return to the System Programming menu.
Select four times.
Frame Format
Use this procedure to specify the framing format for the 100D module as
D4-compatible or Extended Superframe. Your selection must match the framing
mode at the far end of the DS1 facility.
Summary: Frame Format
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
4–86
Programming Procedures
Additional Information
Press Drop.
Dial or type [ n ].
System manager
All
100D module idle
Form 3b, Incoming Trunks: DS1 Connectivity
(100D module)
D4 compatible
D4, ESF
No
No
Select format type
Type slot no.
Dial slot no.
Select format type
