AT&T MERLIN LEGEND Release 3.1 System Programming Manual page 649

Remote Access Features
Console Display/Instructions
3 Erase the current code ( nnnn ).
NN
yy
nnnn
4 Enter a code of up to 11 digits [ N = any combination of 0 to 9 and an asterisk (*)].
5 Continue to assign the code to another barrier code ID number or go to
Step 6.
Next
Next
Select .
6 Save your entry.
Enter Enter
Select .
7 Return to the System Programming menu.
Exit Exit
Select three times.
Remote Access with Barrier Codes
Use this procedure to change the class of restriction for individual remote
access barrier codes. The class of restriction assigned to each barrier code
allows or denies the use of the following system features:
Restriction. Determines whether remote access users can make local
and/or toll calls, and includes the following settings:
Unrestricted
Toll restricted
Outward restricted
ARS Facility Restriction Level (Hybrid/PBX only). Allows or restricts use
of outgoing trunks by assigning a facility restriction level (FRL) from 0
through 6. The FRL ranges from 0 (most restrictive) to 6 (least restrictive).
The FRL value assigned here is the opposite of the FRL value assigned to
the ARS route, where a value of 0 is the least restrictive, and a value of 6
is the most restrictive.
Allowed Lists Assignment. Assigns Allowed Lists and is used when
remote access users are restricted from making local or toll calls.
Disallowed Lists Assignment. Assigns Disallowed Lists and is used when
remote access users are not restricted from making local or toll calls.
xx = barrier code ID number entered in
Step 1
,
yy = barrier code length
Press Drop.
Dial or type [ N ].
Return to Step 3. The next barrier code number
will be displayed on Line 1.
Additional Information
Programming Procedures
PC
F
4–277
