BRI Facilities

BRI Facilities
The procedures in this section provide the steps for programming the following
options for Basic Rate Interface (BRI) facilities connected to a 800 NI-BRI
module:
Service Profile Identifier (SPID) and Directory Number (DN)
Timers
NOTES:
1. The 800 NI-BRI module is only available in Release 4.0 and later.
2. If you are adding BRI facilities to an existing system, clock synchronization
must be set correctly. To inspect or change these values, see "Clock
Synchronization" in "Lines and Trunks."
Service Profile Identifier (SPID) and
Directory Number (DN)
Use this procedure to program the Service Profile Identifier (SPID) and Directory
Number (DN) for each BRI line in the system. Until these values are programmed
for each line, the system will consider the BRI line inactive and the line will not
initialize.
NOTE:
The system will not be forced idle when SPIDs are entered. However, if for some
reason a SPID changes, the line must be idle (no active call on the line) in order
to change the SPID.
Summary: Service Profile Identifier (SPID) and
Directory Number (DN)
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
Key, Hybrid/PBX
Not required
none
SPID: up to 20 digits (any combination of 0 to 9)
DN: up to 10 digits (any combination of 0 to 9)
No
No
LinesTrunks
More
Enter
Dial SPID
Exit
SPID Type DN
BRI SPID/DN
. Dial line/trunk no.
Enter Enter
Dial DN
Type line/trunk no.
Programming Procedures
Exit
Type
4–185
