AT&T MERLIN LEGEND Release 3.1 System Programming Manual page 423

Lines and Trunks
Console Display/Instructions
3 Assign or remove the line/trunk from the specified QCC operator.
Select or
.
4 Continue to assign line/trunk to another QCC operator or go to Step 5.
Select .
5 Return to the System Programming menu.
Select two times.
Block Procedure
1 Specify the block of 20 lines associated with the 20 line buttons on the system
programming console.
Select
2 Assign or remove the lines for the specified QCC operator.
3 Return to the System Programming menu.
Select two times.
Loop-Start Identification Delay
Use this procedure to delay the alerting (ringing) of calls arriving on loop-start
lines/trunks connected to an 800 GS/LS-ID module to all extensions until
approximately six seconds have elapsed since the port module informed the
system software that the line was ringing, or the system software has been
informed that Caller ID information is available, whichever comes first.
This option can be programmed on a per trunk basis. It gives the appearance to
the users that the Caller-ID information is available the moment the call arrives at
the extension, and prevents applications or adjuncts from answering the call too
soon.
You may continue to assign or remove
additional lines/trunks from the QCC
operator by repeating Steps 2 and 3.
Return to Step 2. The next QCC operator
will be displayed on Line 1.
.
Toggle the green LED on or
off as required.
On = operator receiving calls.
Off = operator not receiving calls.
Additional Information
Programming Procedures
PC
4–51
