DS1 Facilities
Console Display/Instructions
10 Enter the channel number ( nn = 1 to 24).
NN
11 Assign or remove the channel.
Select or
.
12 Continue to assign the channel to another slot or go to Step 13.
Select .
13 Save your entry.
Select .
14 Return to the System Programming menu.
Select four times.
Tie Trunk Procedure
1 Specify the emulated trunks as TIE-PBX, Toll or S56 Data.
_
_
_
2 Save your entry.
Select .
Additional Information
**** = option name selected in Step 8
xx = slot entered in Step 3
Dial or type [ nn ].
You may continue to assign or remove
additional channels by repeating the last
two steps.
Return to Step 10. The next slot will be
displayed on Line 1.
xx = slot entered in Step 3
TIE-PBX: Transmit-receive loss set to 0/4.
Toll: Channels used for network services
transmit receive loss set to 0/6.
S56 Data: Channels used for data.
Select ,
Programming Procedures
PC
4–75
