LED Displays
LED Status
Table C–1 indicates LED status on the MLX-20L console. LED status is indicated
on the LEDs next to the 20 buttons below the display area on the system
programming console. LED status is simulated on the computer screen when
you use SPM.
Table C–2 indicates LED status on the DSS console. LED status is indicated on
the red LED next to the 50 extension buttons.
C
System Programming
C–1
