Tie Trunks
Block Procedure
Console Display/Instructions
1 Specify the block of 20 lines associated with the 20 line buttons on the system
programming console.
Select
2 Specify touch-tone or rotary signaling for each line/trunk.
3 Return to the System Programming menu.
Select three times.
Tie Trunk Dial Tone
Use this procedure to specify whether the system provides dial tone for people
calling in on a tie trunk. Settings are remote (system provides dial tone) and local
(system does not provide dial tone).
Summary: Tie Trunk Dial Tone
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure To program a single line/trunk:
.
Toggle the green LED on or
off as required.
On = touch-tone.
Off = rotary.
System manager
All
Not required
Form 3c, Incoming Trunks: Tie
Remote
Remote, Local
Yes
Yes
trunk no.
To program a block of lines/trunks:
lines/trunks Toggle LED On/Off
Additional Information
or
Programming Procedures
PC
!
"
###
E
Dial
Select block of
4–105
