To do...
Display information about LDP
sessions
Display information about LSPs
established by LDP
Display information about
CR-LSPs established by
CR-LDP
Display information about a
specified LDP instance

Clearing MPLS Statistics

To do...
Clear MPLS statistics for one or
all MPLS interfaces
Clear MPLS statistics for all
LSPs or the LSP with a
specified index or name

MPLS Configuration Examples

Example for Configuring LDP Sessions

Network requirements
Switch A, Switch B, and Switch C support MPLS and use OSPF as the IGP for the MPLS
backbone.
Local LDP sessions are established between Switch A and Switch B as well as between Switch B
and Switch C, while a remote LDP session is required between Switch A and Switch C.
Use the command...
display mpls ldp session [ all
[ verbose | statistics ] |
[ vpn-instance
vpn-instance-name ] [ peer-id |
verbose ] ] [ | { begin | exclude
| include } regular-expression ]
display mpls ldp lsp [ all |
[ vpn-instance
vpn-instance-name ]
[ dest-addr mask-length ] ] [ |
{ begin | exclude | include }
regular-expression ]
display mpls ldp cr-lsp
[ vpn-instance
vpn-instance-name [ lspid
lsr-id lsp-id ] ] [ | { begin |
exclude | include }
regular-expression ]
display mpls ldp
vpn-instance
vpn-instance-name [ | { begin |
exclude | include }
regular-expression ]
Use the command...
reset mpls statistics
interface { interface-type
interface-number | all }
reset mpls statistics lsp
{ index | all | name lsp-name }
1-33
Remarks
Available in any view
Available in any view
Available in any view
Available in any view
Remarks
Available in user view
Available in user view
