After completing the above configurations, you will find by issuing the following commands on Switch A
that the remote LDP session with Switch C is already established:
[SwitchA] display mpls ldp session
Total number of sessions: 2
----------------------------------------------------------------
Peer-ID
----------------------------------------------------------------
2.2.2.9:0
3.3.3.9:0
----------------------------------------------------------------
LAM : Label Advertisement Mode
[SwitchA] display mpls ldp peer
LDP Peer Information in Public network
Total number of peers: 2
-----------------------------------------------------------------
Peer-ID
-----------------------------------------------------------------
2.2.2.9:0
3.3.3.9:0
-----------------------------------------------------------------

Example for Configuring LDP to Establish LSPs

Network requirements
On the network in
and reachability of the LSP.
Configuration procedure
1) Configure LDP sessions. Refer to
2) Configure the LSP establishment triggering policy for LDP to establish LSPs.
For LDP to establish an LSP, LDP sessions are required between neighboring routers along the LSP. In
Figure 1-10, an LDP LSP can be established from Switch A to Switch C provided that local LDP
sessions exist between Switch A and Switch B, and between Switch B and Switch C; no remote LDP
session is required between Switch A and Switch C.
# Configure Switch A.
[SwitchA] mpls
[SwitchA-mpls] lsp-trigger all
[SwitchA-mpls] return
# Configure Switch B.
LDP Session(s) in Public Network
Status LAM SsnRole
Operational DU Passive
Operational DU Passive
Transport-Address
2.2.2.9
3.3.3.9
Figure 1-10, an LSP is required between Switch A and Switch C. Check the validity
Example for Configuring LDP Sessions
FT MD5 KA-Sent/Rcv
Off Off 35/35
Off Off 8/8
FT : Fault Tolerance
Discovery-Source
Vlan-interface10
Remote Peer : peerc
