Intermixing
Configuration Task
Introduction to
intermixing
configuration task
Configuring Routing
Protocols
Configuring Basic
Capability of MPLS
It is not allowed to make the redirected source port or destination port to leave
■
redirected VLAN in the normal way;
It is not allowed to configure protocol VLANs on the redirected source port or
■
destination port;
It is not allowed to delete the redirected VLAN or VLAN interface;
■
It is not allowed to configure/add Loopback ports in the redirected VLAN;
■
It is not allowed to use STP edge port as the redirected destination port;
■
It is not allowed to change the VLANs and the default VLAN ID which the
■
redirected destination port is permitted to pass;
If normal ports are used, 4,094 VLL VPNs are supported; if the Trunk port of the
■
card of a fast Ethernet card is used, a maximum of 1024 VLL VPNs are
supported;
A Trunk-type 100M Ethernet port can use only 1024 VLANs for VPN access or
MPLS forwarding, but you can specify the start VLAN ID of the 100M Ethernet
Trunk port. Assume the start VLAN ID is VLAN ID, the range of VLAN IDs of the
VLANs that pass a certain 100M Ethernet port is from VLAN ID to VLAN ID + 1023.
Table 559 Introduction to intermixing configuration task
Operation
Configure public network
routing protocols
Configure the basic capability
of MPLS
Configure MPLS VPN
Configure flow template and
ACL rules
Apply flow template on the
port and configure redirection
The Switch should be configured with some basic routing configurations so that it
can exchange public network routing information with other P devices and PE
devices. The routing protocols available currently include: static routing, RIP, OSPF,
BGP and so on. Refer to the "Routing Protocols" part of the 3Com Switch 8800
Family Routing Switches Operation Manual Volume I for detailed configuration
information.
Configure MPLS basic capability to enable MPLS and LDP globally and on the
public network interface, to establish an LSP tunnel for the public network. Refer
to "MPLS Basic Capability Configuration" for detailed configuration information.

Intermixing Configuration Task

Description Related section
Section "Configuring Routing Protocols"
Required
"Configuring Routing Protocols"
Required "MPLS Basic Capability Configuration"
Required "BGP/MPLS VPN Configuration"
Section "Configuring flow template and
Required ACL rules" "Configuring flow template and
ACL rules"
Section "Applying Flow Template and
Required Redirection in Port Mode" "Applying Flow
Template and Redirection in Port Mode"
603
