Configuring Protocol-Based Vlan - 3Com 8807 Configuration Manual

Configuring Port-Based
VLAN
Configuring
Protocol-Based VLAN
Creating/Deleting a
VLAN Protocol Type
Associating/Dissociating
a Port with/from a
Protocol-Based VLAN
You can use the following commands to specify Ethernet ports for a VLAN.
Perform the following configuration in VLAN view.
Table 38 Specify Ethernet ports for a VLAN
Operation
Add Ethernet ports to a VLAN
Remove Ethernet ports from a VLAN
By default, the system adds all the ports to a default VLAN whose ID is 1.
Note that you can add/remove the trunk and Hybrid ports to/from a VLAN by the
port/undo port commands in Ethernet port view, but not in VLAN view.
The following sections describe the protocol-based VLAN configuration tasks:
"Creating/Deleting a VLAN Protocol Type"
■
"Associating/Dissociating a Port with/from a Protocol-Based VLAN"
■
You can use the following commands to create/delete a VLAN protocol type.
Perform the following configuration in VLAN view.
Table 39 Create/Delete a VLAN protocol type
Operation
Create a VLAN protocol type
Delete an existing VLAN protocol type
Perform the following configuration in Ethernet port view.
Table 40 Associate/Dissociate a port with/from a protocol-based VLAN
Operation
Associate a port with a protocol-based VLAN
Remove a port from a protocol-based VLAN
n
The port to be associated with a protocol-based VLAN must be of Hybrid type
■
and in this VLAN.
The same protocol can be configured in the different VLANs, but cannot be
■
configured repeatedly in the same VLAN.
A port cannot be associated with different VLANs with the same protocols
■
configured.

Configuring Protocol-Based VLAN

Command
port interface-list
undo port interface-list
Command
protocol-vlan [ protocol-index ] { at | ipx {
ethernetii | llc | raw | snap } | mode {
ethernetii etype etype-id | llc dsap dsap-id
ssap ssap-id | snap etype etype-id } }
undo protocol-vlan { protocol-index [ to
protocol-end ] | all }
Command
port hybrid protocol-vlan vlan vlan-id {
vlan-protocol-list | all }
undo port hybrid protocol-vlan vlan {
vlan-id { vlan-protocol-list | all } | all }
57
