170 C 21: ACL C
HAPTER
Configuring Time Range
ONFIGURATION
Table 145 ACL configuration tasks on interface cards
Item
Activate the ACL
The following table describes the configuration tasks for service processor cards.
Table 146 ACL configuration tasks for service processor cards
Item
Enter system view
Configure the time range
Enter ACL view
Define rules
Exit ACL view
Enter Ethernet port view
Configure traffic redirection in
Ethernet port view to redirect
the packets of a specific VLAN
to a service processor card
Exit Ethernet port view
Enter VLAN view
Activate the ACL in VLAN
view
You may set such items in time range configuration: The defined time range
includes absolute time range and periodic time range. The absolute time range is
in the form of hh:mm YYYY/MM/DD; the periodic time range is in the format of
hh:mm, day.
Perform the following configurations in system view.
Table 147 Configure/Delete time range
Operation
Create time range
Command
packet-filter inbound
Command
system-view
time-range time-name {
start-time to end-time
days-of-the-week [ from
start-time start-date ] [ to
end-time end-date ] | from
start-time start-date [ to
end-time end-date ] | to
end-time end-date }
acl { number acl-number |
name acl-name [ advanced |
basic ] } [ match-order {
config | auto } ]
rule
quit
interface interface-type
interface-number
traffic-redirect inbound
ip-group
quit
vlan vlan-id
packet-filter inbound
ip-group { acl-number |
acl-name } [ rule rule [
system-index index ] ] slot
slotid
Command
time-range time-name { start-time to end-time days-of-the-week [
from start-time start-date ] [ to end-time end-date ] | from start-time
start-date [ to end-time end-date ] | to end-time end-date }
Description
Required
Description
-
Optional
Required. Service processor
cards do not support Layer 2
ACL.
Required
-
-
Required. See section
"Configuring Traffic
Redirection" "Configuring
Traffic Redirection"
-
You must enter the VLAN
view specified by the
redirection function.
Required
