58 C 7: VLAN C
HAPTER
Configuring IP
Subnet-Based VLAN
Associating/Dissociating
a Specified Port
with/from an IP
Subnet-Based VLAN
Configuring/deleting an
IP Subnet-Based VLAN
Configure the CPU
Port in an VLAN
ONFIGURATION
You cannot delete a protocol-based VLAN that has ports associated with.
■
You cannot delete a protocol-based VLAN on a port while the port is associated
■
with the VLAN.
The following sections describe the IP subnet-based VLAN configuration tasks:
Associating/dissociating a specified port with/from an IP subnet-based VLAN
■
Configuring an IP subnet-based VLAN
■
Use the following commands to associate/dissociate a specified port with/from an
IP subnet-based VLAN.
Perform the following configuration in Ethernet port view.
Table 41 Associate/dissociate a port with/from an IP subnet-based VLAN
Operation
Associate a specified port with an IP
subnet-based VLAN
Remove a specified port from an IP
subnet-based VLAN
Perform the following configuration in VLAN view.
Table 42 Configure/delete an IP subnet-based VLAN
Operation
Create an IP subnet-based VLAN
Delete an IP subnet-based VLAN
The CPU is a special port in the Switch 8800 Family series routing switches. By
default, because the CPU port is in a VLAN, when common broadcast packets and
unknown multicast packets are broadcast within a VLAN, these packets will also
be broadcast to the CPU. To prevent waste of CPU resources, you can move the
CPU port out of the VLAN, so that common broadcast packets and unknown
multicast packets will not be handed to the CPU for processing.
You can use the following command to move the CPU port out of the VLAN.
Perform the following configuration in VLAN view.
Table 43 Move the CPU port out of/into the VLAN
Operation
Move the CPU port out of the VLAN
Move the CPU port into the VLAN
By default, the CPU port is in the VLAN.
Command
port hybrid ip-vlan vlan vlan-id
undo port hybrid ip-vlan vlan vlan-id
Command
vlan-type ip-subnet ip ip-address { [
net-mask | net-mask-length ] }
undo vlan-type ip-subnet { index-begin [ to
index-end ] | all }
Command
trap-to-cpu disable
undo trap-to-cpu disable
