3Com 8807 Configuration Manual page 542

542 C 49: BGP/MPLS VPN C
HAPTER
c
c
ONFIGURATION
Table 530 Configure the vlan-id range of MPLS/VPN VLANs allowed
Operation
Configure the vlan-id range of MPLS/VPN
VLANs allowed to pass Trunk fast Ethernet
ports
Remove the configured vlan-id range of
MPLS/VPN VLANs allowed to pass Trunk fast
Ethernet ports
By default, the vlan-id range of MPLS/VPN VLANs is from 0 to 1023, and the
default value of vlan-id is 0. The value range of vlan-id is from 1 to 3071.
CAUTION:
This command can only be executed on Trunk ports, and MPLS/VPN-enabled
■
VLANs and VLANs out of the configured range are excluded..
Set the VPN range for the cards and set the range of MPLS/VPN VLAN vlan-id
■
on the interface of the card to 1 to 4094.
Perform the following configuration in system view.
Table 531 Configure the MPLS/VPN VLAN vlan-id range for the card
Operation
Enable the 4K VPN-range for the card
Disable the 4K VPN-range for the card
CAUTION:
This command is actually effective for only the first 12 ports on the card. When
■
you configure MPLS/VPN VLAN vlan-id on subsequent ports, only the
MPLS/VPN VLAN range enabled for one VLAN will take effect. If you remove
MPLS/VPN configuration from an active port, no subsequent port will take
effect automatically either, and you have to reconfigure the ports to update
their states.
Restart the card after issuing a command or its corresponding undo command
■
to ensure that the configuration takes effect.
After you cancel card configuration, if the VLAN configured on a port exceeds
■
1K, which is the default value, the configuration will be deleted automatically.
In aggregation mode, VPN-range configuration will not be synchronized
■
automatically and you can manually make/remove the configuration on an
individual port.
Set the VPN range for the ports and set the range of MPLS/VPN VLAN vlan-id
■
on the ports to 1 to 4094.
Perform the following configuration in Ethernet interface view.
Table 532 Configure the MPLS/VPN VLAN vlan-id range for the interface
Operation
Enable the 4K vpn-range for the interface
Command
port trunk mpls vlan from vlan-id [ to ]
vlanid
undo port trunk mpls
Command
vlan vpn-range slot slot-number enable
undo vlan vpn-range slot slot-number
enable
Command
port vpn-range share-mode enable
