Energy Measurement Object (E4h)
Attr ID# Access Rule Name
13 Get Apparent Power
14 Get Min Apparent Power
15 Get Max Apparent Power
16 Get Active Power
17 Get Min Active Power
SCM-1202-021 Version 2.6
®
Anybus CompactCom
Data Type Element number:description
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Total TS
FLOAT 10: Total Value
UINT32 11: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Total TS
FLOAT 10: Total Value
UINT32 11: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Total TS
FLOAT 10: Total Value
UINT32 11: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Total TS
FLOAT 10: Total Value
UINT32 11: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
™
40 - PROFINET IRT Transparent
Ethernet
PROFIenergy Measurement ID
10
11
12
36
79
80
81
97
49
50
51
67
13
14
15
34
82
