HMS Networks Anybus CompactCom 40 Network Manual page 158

® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
2.5. Port Activity
AIDA LED State Description
Off No Activity
Orange, flashing Activity
There is no LED on the front of the Anybus CompactCom 40 PROFINET IRT showing this indication, but the signal
is available in the host application connector according to this table:
AIDA indication Signal Name, Host Application Connector
Activity on port 1 nLED3B
Activity on port 2 nLED4B
The Port Activity signals are always available in the host application connector in all operating modes except 16
bit parallel. For more information consult the Anybus CompactCom M40 Hardware Design Guide (module) or the
Anybus CompactCom B40-1 Design Guide (brick).
When Transparent Ethernet is activated, the LED status signals are only available in the LED status register.
Page 150 of 177
Anybus CompactCom AIDA LED Mode
SCM-1202-021 Version 2.6
