Network Configuration Object (04h)
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
IMPORTANT
Do not set this unless the end user explicitly would like to turn DHCP on. Normally the PROFINET IO
Controller assigns the IP address.
10.5.9. Instance Attributes (Instance #9, DNS1)
This instance holds the address to the primary DNS server. Changes are valid after reset.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured Value
SCM-1202-021 Version 2.6
Access Data Type Description
Get Array of CHAR "DHCP"
(Multilingual, see page
Get UINT8 08h (= ENUM)
Get UINT8 01h (one element)
Get UINT8 07h (read/write/shared access)
Get/Set ENUM If read, the actual value will be received. If written, the written
value is reflected in attribute #6 until a reset. (Multilingual, see page
Multilingual Strings (page
Value
00h
01h
Get ENUM Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Value
00h
01h
Access Data Type Description
Get Array of CHAR "DNS1"
(Multilingual, see page
Get UINT8 04h (= UINT8)
Get UINT8 04h (four elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of UINT8 If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Get Array of UINT8 Holds the configured value, which will be written to attribute #5 after
the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Multilingual Strings (page
54))
String Meaning
"Disable" DHCP disabled (default)
"Enable" DHCP enabled
String Meaning
"Disable" DHCP disabled
"Enable" DHCP enabled
Multilingual Strings (page
Ethernet
54))
54))
