Network Configuration Object (04h)
10.5.14. Instance Attributes (Instance #20, Station Name)
The Station Name identifies the Anybus module on PROFINET. If this value is changed by the host application
during runtime, a reset is required in order for changes to have effect. Changes made through DCP will have
immediate effect, however.
The Station Name field shall be coded as data type CHAR with 1 to 240 characters. The definition of RFC 5890
and the following syntax applies:
• 1 or more labels, separated by [.]
• Total length is 1 to 240
• Label length is 1 to 63
• Labels consist of [a-z, 0-9, -]
• Labels do not start with [-]
• Labels do not end with [-]
• The first label must not have the form "port-xyz" or "port-xyz-abcde", where a, b, c, d, e, x, y, z = 0...9, to avoid
similarity with the field AliasNameValue
• Station names must not have the form n.n.n.n, where n = 0...999
IMPORTANT
If the Station name does not pass validation by the Anybus module, an error response with error
code 0Ch will be returned to the application and the Station name will not be changed/saved.
# Name
1 Name
2 Data type
3 Number of elements
4 Descriptor
5 Value
6 Configured value
IMPORTANT
This attribute shall normally not be set by the application. The station name is normally set by the
end user via the network. The host application shall use this attribute when the end user has the
possibility to edit the station name through the application, and chooses to do so.
This attribute should not be set by the application at every power on, as this would cause
certification problems.
10.5.15. Instance Attributes (Instance #21, F-Address)
This instance holds the F-Address, which is the PROFIsafe address for the safety module. This instance has no
effect unless the attribute #1 (Safety enabled) is set to TRUE in the Functional Safety host object (instance #1). If
the attribute is set to FALSE in the Functional Safety host object the application is advised to hide this instance to
the end user. See Functional Safety Object (E8h) (page 100)
If this value is changed by the host application during runtime, a reset is required in order for changes to have
effect.
SCM-1202-021 Version 2.6
Access Data Type Description
Get Array of CHAR "Station name"
(Multilingual, see page
Get UINT8 07h (= CHAR)
Get UINT8 F0h (240 elements)
Get UINT8 07h (read/write/shared access)
Get/Set Array of CHAR The current Station name
If read, the actual value will be received. If written, the written value is
reflected in attribute #6 until a reset.
Get Array of CHAR Holds the configured value, which will be written to attribute #5 after
the module has been reset.
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Multilingual Strings (page
Ethernet
54))
