PROFINET IO Object (F6h)
Data Format
When all data has been received, the resulting data shall be interpreted as follows:
Type Name
UINT16 iNbrApi
UINT32 iApiNbr
UINT16 iNbrMod
UINT16 iSlotNbr
UINT16 iNbrSubMod
UINT32 lModIdent
UINT16
UINT32
UINT16
UINT16
The initial API block (iNbrApi) defines the number of APIs in the configuration.
Each API has an initial module block, that includes information on the API number (iApiNbr) and the number of
modules (or slots) in the API.
Each module starts with a module block, which holds the slot number, the number of submodules (or subslots)
and the module identity number.
Finally each submodule block holds subslot number, submodule identification number, input and output data
lengths.
SCM-1202-021 Version 2.6
Description
Number of APIs in configuration
Initial module block including API number and number of module blocks in the API.
Module block (8 bytes), see below.
iSubSlotNbr Submodule block (10 bytes), see below.
lSubModIdent
iInDataLength
iOutDataLength
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
