Major unrecoverable events cause the module to disconnect itself from the network, thus preventing network
participation. Other severity levels either produce a Channel Diagnostic entry/alarm or a Generic Diagnostic
entry/alarm, depending on the Event Code:
Event Code Result
0...FEh Module issues a Channel Diagnostic entry/alarm. The Event Code will be translated and represented as the Channel Error Type as
follows:
Code:
10h
20h
21h
22h
23h
30h
31h
32h
33h
40h
41h
42h
50h
60h
61h
62h
63h
70h
80h
81h
82h
90h
F0h
FFh Module issues a Generic Diagnostic entry/alarm based on network specific data.
See details below.
10.3.6. Details: Network Specific Data
Network specific diagnostic data serves as the payload in the PROFINET diagnostic alarm. The data contains an
identifier (UserStructureIdentifier) that describes the structure of the data.
The following identifier values are supported:
• 8000h (Channel Diagnostic)
• 8002h (Extended Channel Diagnostic)
• 8003h (Qualified Channel Diagnostic)
Byte Contents
1 UserStructureIdentifier, low byte
2 UserStructureIdentifier, high byte
3... 16 Data
Page 42 of 177
Event (Anybus):
Generic Error
Current
Current, device input side
Current, inside the device
Current, device output side
Voltage
Mains Voltage
Voltage inside the device
Output Voltage
Temperature
Ambient Temperature
Device Temperature
Device Hardware
Device Software
Internal Software
User Software
Data Set
Additional Modules
Monitoring
Communication
Protocol Error
External Error
Additional Functions
Diagnostic Object (02h)
Channel Error Type (PROFINET):
Error
Short circuit
Short circuit
Short circuit
Short circuit
Overvoltage
Overvoltage
Overvoltage
Overvoltage
Overtemperature
Overtemperature
Overtemperature
Error
Error
Error
Error
Error
Error
Error
Error
Error
Error
Error
