Network Ethernet Object (0Ch)
10.7.5. Instance Attributes (Instances #1 - #3)
# Name
1 MAC Address
2 Port 1 MAC Address
3 Port 2 MAC Address
4 MAC Address
5 Interface Counters
6 Media Counters
10.7.6. Interface Counters
Array indices of Interface Counters attribute (#5)
Index Name
0 In Octets
1 In Unicast Packets
2 In Non-Unicast Packets
3 In Discards
4 In Errors
5 In Unknown Protos
6 Out Octets
7 Out Unicast packets
8 Out Non-Unicast Packets
9 Out Discards
10 Out Errors
SCM-1202-021 Version 2.6
Access Data Type Description
Get Array of UINT8 Reserved, used for backwards compatibility.
(Device MAC address.)
(See also
Get Array of UINT8 Reserved, used for backwards compatibility.
(MAC address for port 1 (mandatory for the LLDP protocol))
(See also
Get Array of UINT8 Reserved, used for backwards compatibility.
(MAC address for port 2 (mandatory for the LLDP protocol))
(See also
Get Array of UINT8 MAC address of the port.
Get Array of UINT32 Array containing MIB-II interface counters (rfc1213)
See table below for array indices.
Get Array of UINT32 Array containing Ethernet-Like MIB counters for the port.
See table below for array indices.
Description
Octets received on the interface
Unicast packets received on the interface
Non-unicast packets (multicast/broadcast) packets received on the interface
Inbound packets received on the interface but discarded
Inbound packets that contain errors (does not include In Discards)
Inbound packets with unknown protocol
Octets transmitted on the interface
Unicast packets transmitted on the interface
Non-unicast (multicast/broadcast) packets transmitted on the interface
Outbound packets discarded
Outbound packets that contain errors
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet Host Object (F9h) (page 132))
Ethernet Host Object (F9h) (page 132))
Ethernet Host Object (F9h) (page 132))
NOTE
This attribute is not valid for the internal port, i.e.
instance #1 of the object.
Ethernet
