PROFINET IO Object (F6h)
• Response Details (Error)
Field Contents
CmdExt[0... 1] (reserved)
MsgData[0] FFh
MsgData[1] Error Code 1
MsgData[2] Error Code 2
MsgData[3] Additional Data 1
MsgData[4] Additional Data 2
See also...
• Details for the command Set_Record (below)
• Flowchart — Record Data Access (page 139)
SCM-1202-021 Version 2.6
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Comments
(set to zero)
Object specific error
See Details: Error Code 1 (page 131)
User specific error code
API specific. Set to zero if no Additional Data 1 is defined.
User specific. Set to zero if no Additional Data 2 is defined.
