11.7.7. Command Details: Set_Record
Category
Extended
Details
Command Code: 11h
Valid For: Object Instance
Description
The module issues this command in the following situations:
• Module receives a Record Data Write request towards an API other than 0 (zero).
• Module receives a Record Data Write request towards API 0, but the record in question is handled in
Transparent Mode
See instance attribute #7 for more information about Transparent Mode.
See "Flowchart - Record Data Access" on page 154 for more information.
It is optional to implement support for this command. If not implemented, the original network request will be
rejected and an error is returned to the IO Controller/Supervisor.
• Command Details
Field Contents
CmdExt[0] AR handle (low byte)
CmdExt[1] AR handle (high byte)
MsgData[0] API (low word, low byte)
MsgData[1] API (low word, high byte)
MsgData[2] API (high word, low byte)
MsgData[3] API (high word, high byte)
MsgData[4] Slot (low byte)
MsgData[5] Slot (high byte)
MsgData[6] Subslot (low byte)
MsgData[7] Subslot (high byte)
MsgData[8] Index (low byte)
MsgData[9] Index (high byte)
MsgData[10] (reserved)
MsgData[11.. n] Data (up to 1512 bytes)
• Response Details (Success)
(no data)
• Response Details (Error)
Field Contents
CmdExt[0... 1] (reserved)
MsgData[0] FFh
MsgData[1] Error Code 1
MsgData[2] Error Code 2
MsgData[3] Additional Data 1
MsgData[4] Additional Data 2
Page 118 of 177
PROFINET IO Object (F6h)
Comments
Handle for Application Relationship (AR)
Application Process Instance (API)
Slot number of request
Subslot number of request
Index of request
(set to zero)
Data from the Record Data Write request.
Comments
(set to zero)
Object specific error
See Details: Error Code 1 (page 131)
User specific error code
API specific. Set to zero if no Additional Data 1 is defined.
User specific. Set to zero if no Additional Data 2 is defined.
