Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.2.6. Command Details: Get_Attribute_Measurement_List
Details
Command Code: 10h
Valid For: Instance
Description
This command is used to gather all supported attribute elements of an instance. If several instances are
supported, the command will be sent numerous times (implied by object attribute Highest instance number).
Based on the response(s) the Anybus CompactCom will provide information to the network indicating which
measurement values that are supported by a device.
The command response shall contain all attributes up to the last supported attribute number. For unsupported
attributes within this range the bit field shall be set to zero.
The table below shows an example of the expected response for a (multiple phase) device supporting several
measurement values for attributes #1, #4 and #10.
Data[0-1] 0x000F
Data[2-3] 0x0000
Data[4-5] 0x0000
Data[6-7] 0x000F
Data[8-9] 0x0000
Data[10-11] 0x0000
Data[12-13] 0x0000
Data[14-15] 0x0000
Data[16-17] 0x0000
Data[18-19] 0x000F
The table below shows an example of the expected response for a (single phase) device supporting one
measurement value for attributes #1, #4 and #10.
Data[0-1] 0x0001
Data[2-3] 0x0000
Data[4-5] 0x0000
Data[6-7] 0x0001
Data[8-9] 0x0000
Data[10-11] 0x0000
Data[12-13] 0x0000
Data[14-15] 0x0000
Data[16-17] 0x0000
Data[18-19] 0x0001
• Command Details
Field Contents
CmdExt[0 - 1] Reserved, set to 00h
Page 94 of 177
Attribute #1 - measurement values 1-4 supported (i.e. L1-L2-L3-Avg)
Attribute #2 - attribute not supported
Attribute #3 – attribute not supported
Attribute #4 - measurement values 1-4 supported (i.e. L1-L2-L3-Avg)
Attribute #5 – attribute not supported
Attribute #6 – attribute not supported
Attribute #7 – attribute not supported
Attribute #8 – attribute not supported
Attribute #9 – attribute not supported
Attribute #10 – measurement values 1-4 supported (i.e. L1-L2-L3-Avg)
Attribute #1 - measurement value 1 supported (i.e. L1)
Attribute #2 - attribute not supported
Attribute #3 – attribute not supported
Attribute #4 - measurement value 1 supported (i.e. L1)
Attribute #5 – attribute not supported
Attribute #6 – attribute not supported
Attribute #7 – attribute not supported
Attribute #8 – attribute not supported
Attribute #9 – attribute not supported
Attribute #10 – measurement values 1 supported (i.e. L1)
Energy Measurement Object (E4h)
