Identification & Maintenance (I&M)
4.7.2. I&M Data Structures
The I&M records uses the following data structures.
Record Content Size
I&M0 Manufacturer Id 2 bytes
Order Id 20 bytes
Serial number 16 bytes
Hardware revision 2 bytes
Software revision 4 bytes
Revision counter 2 bytes
Profile Id 2 bytes
Profile specific type 2 bytes
IM version 2 bytes
IM supported 2 bytes
I&M1 Tag Function 32 bytes
Tag Location 22 bytes
I&M2 Installation date 16 bytes
I&M3 Descriptor 54 bytes
I&M5 IM_Annotation 64 bytes
IM_OrderID 64 bytes
VendorIDHigh 1 byte
VendorIDLow 1 byte
Serial number 16 bytes
Hardware revision 2 bytes
Software revision 4 bytes
See also..
• PROFINET IO Object (F6h) (page 112)
• Anybus CompactCom 40 Software Design Guide, Application Object (FFh)
SCM-1202-021 Version 2.6
Description
PROFINET IO Object (F6h), attribute #2 (Vendor ID/I&M Vendor ID)
PROFINET IO Object (F6h), attribute #8 (I&M Order ID)
The content will be assigned in the following priority order:
1. PROFINET IO Object (F6h), attribute #9 (I&M Serial number)
2. Application Object (FFh), attribute #3 (Serial number)
3. Default value, assigned during manufacturing
The content will be assigned in the following priority order:
1. PROFINET IO Object (F6h), attribute #10 (I&M Hardware revision)
2. Application Object (FFh), attribute #11 (Hardware version)
3. Default value, assigned during manufacturing
The content will be assigned in the following priority order:
1. PROFINET IO Object (F6h), attribute #11 (I&M Software revision)
2. Application Object (FFh), attribute #10 (Firmware version)
3. Default value, assigned during manufacturing
PROFINET IO Object (F6h), attribute #12 (I&M Revision counter)
PROFINET IO Object (F6h), attribute #13 (I&M Profile ID)
PROFINET IO Object (F6h), attribute #14 (I&M Profile specific type)
0101h (Internal, constant value)
For submodules belonging to a "non–zero API",the returned value is zero. For submodules belonging
to API 0, the returned value is 000Eh (IM0-3 supported)
Default: All bytes set to blanks
Default: All bytes set to blanks
Default: All bytes set to blanks
Default: All bytes set to blanks
PROFINET IO object; attribute #26 (IM Annotation). If the application doesn't support the attribute:
Anybus CompactCom 40 PROFINET IRT
PROFINET IO object; attribute #25 (IM Module Order ID). If the application doesn't support the
attribute: Anybus CompactCom 40 PROFINET IRT
01h
0Ch
Serial number of the Anybus CompactCom
Hardware version of the Anybus CompactCom
Product version of the Anybus CompactCom
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
