File System Interface Object (0Ah)
10.5.17. Command Details: Reset
Category
Details
Command Code: 05h
Valid For: Object Instance
Description
A reset command to this object will result in that all instances are set to their default values.
It is optional to implement support for this command.
• Command Details
Field Comments
CmdExt[0] 00h (Reserved)
CmdExt[1] 01h (Factory default reset)
• Response Details
(No data)
10.6. File System Interface Object (0Ah)
10.6.1. Category
Extended
10.6.2. Object Description
This object provides an interface to the built-in file system. Each instance represents a handle to a file stream and
contains services for file system operations.
This object is thoroughly described in Anybus CompactCom 40 Software Design Guide.
