Energy Control Object (F0h)
Command Details: Start_Pause
Details
Command Code: 10h
Valid For: Object
Description
This command is sent to the host application when the system wants to initialize a pause of the system. The
length of the pause is specified in milliseconds. The response of the message contains the destination mode (i.e.
the instance number of the selected energy saving mode).
• Command Details
Field Contents
Data[0] Pause time (low word, low byte)
Data[1] Pause time (low word, high byte)
Data[2] Pause time (high word, low byte)
Data[3] Pause time (high word, high byte)
• Response Details
Field Contents
Data[0] Instance number (low byte)
Data[1] Instance number (low byte)
If the application is unable to select a state, given the requested pause time, it shall return one of the error
codes in the table below.
# Error code Description
0x0D Invalid state Given the state of the device and the requested pause time it is currently not possible to enter any energy saving mode
0x12 Value too low The requested pause time is too short
SCM-1202-021 Version 2.6
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Comments
Pause time (ms)
Comments
Instance number of selected Energy mode
