Functional Safety Object (E8h)
11.4.5. Instance Attributes (Instance #1)
# Name
1 Safety enabled
2 Baud Rate
3 (reserved)
4 Cycle Time
5 FW upgrade in progress
SCM-1202-021 Version 2.6
Access Data Type Default Value
Get BOOL -
Get UINT32 1020 kbit/s
Get UINT8 -
Set BOOL False
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Comment
When TRUE, enables communication with the Safety
Module.
NOTE
If functional safety is not supported, this
attribute must be set to FALSE.
This attribute sets the baud rate of the communication
in bits/s between the Anybus CompactCom and the
Safety Module.
Valid values:
• 625 kbit/s
• 1000 kbit/s
• 1020 kbit/s (default)
Any other value set to this attribute, will cause the
module to enter the EXCEPTION state.
The attribute is optional. If not implemented, the default
value will be used.
NOTE
The host application shall never
implement this attribute when using the
IXXAT Safe T100.
Communication cycle time between the Anybus and the
Safety module in milliseconds.
NOTE
The host application shall never
implement this attribute when using the
IXXAT Safe T100.
Valid values:
• 2 ms
• 4 ms
• 8 ms
• 16 ms
If another value is set in this attribute the Anybus will
enter Exception state.
Optional attribute; If not implemented the minimum
cycle time for the chosen baud rate will be used:
• 2 ms for 1020 kbit/s
• 2 ms for 1000 kbit/s
• 4 ms for 625 kbit/s
The Anybus CompactCom validates the cycle time
according to the minimum values above. If e.g. baud rate
is 625 kbit/s and the cycle time is set to 2 ms the Anybus
CompactCom will enter the EXCEPTION state.
Indicates if the Anybus CompactCom is upgrading the
connected Safety module firmware. This means that
the Anybus CompactCom will stay in the NW_INIT state
longer than normal.
