Ethernet Host Object (F9h)
# Name
1 MAC address
2 Enable HICP
3 Enable Web Server
4 (reserved)
5 Enable Web ADI access
6 Enable FTP server
7 Enable admin mode
8 Network Status
9 Port 1 MAC address
10 Port 2 MAC address
11 Enable ACD
12 Port 1 State
13 Port 2 State
SCM-1202-021 Version 2.6
Access Data Type Default Value
Get Array of UINT8 -
Get BOOL True (Enabled)
Get BOOL True (Enabled)
Get BOOL True (Enabled)
Get BOOL True (Enabled)
Get BOOL False (Disabled)
Set UINT16 -
Get Array of UINT8 -
Get Array of UINT8 -
Get BOOL True (Enabled)
Get ENUM 0 (Enabled)
Get ENUM 0 (Enabled)
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Comment
6 byte physical address value; overrides the
preprogrammed Mac address. Note that the new
Mac address value must be obtained from the
IEEE.
Do not implement this attribute if the
preprogrammed Mac address is to be used.
Enable/Disable HICP
Enable/Disable Web Server
(Not used if Transparent Ethernet is enabled.)
Reserved for Anybus CompactCom 30 applications.
Enable/Disable Web ADI access
(Not used if Transparent Ethernet is enabled.)
Enable/Disable FTP server
(Not used if Transparent Ethernet is enabled or if
device supports IIoT secure functionality.)
Enable/Disable admin mode
(Not used if Transparent Ethernet is enabled.)
See below.
Note: This attribute is only valid for PROFINET
devices. 6 byte MAC address for port 1 (mandatory
for the LLDP protocol).
This setting overrides any Port MAC address in the
host PROFINET IO Object.
Do not implement this attribute if the
preprogrammed Mac address is to be used.
Note: This attribute is only valid for PROFINET
devices. 6 byte MAC address for port 2 (mandatory
for the LLDP protocol).
This setting overrides any Port MAC address in the
host PROFINET IO Object.
Do not implement this attribute if the
preprogrammed Mac address is to be used.
Enable/Disable ACD protocol.
If ACD functionality is disabled using this attribute,
the ACD attributes in the CIP TCP/IP object (F5h)
are not available.
The state of Ethernet port 1.
• This attribute is not read by EtherCAT and
Ethernet POWERLINK devices, where Port 1 is
always enabled.
00h: Enabled
01h: Disabled.
The port is treated as existing.
References to the port can exist, e.g.
in network protocol or on website.
The state of Ethernet port 2.
• This attribute is not read by EtherCAT and
Ethernet POWERLINK devices, where Port 2 is
always enabled.
00h: Enabled
01h: Disabled.
The port is treated as existing.
References to the port can exist, e.g.
in network protocol or on website.
Ethernet
