HMS Networks Anybus CompactCom 40 Network Manual page 142

® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
# Name
14 (reserved)
15 Enable reset from HICP
16 IP configuration
17 IP address byte 0–2
18 Ethernet PHY
Configuration
20 SNMP read-only
community string
21 SNMP read-write
community string
22 DHCP Option 61 source
23 DHCP Option 61 generic
string
24 Enable DHCP Client
25 Enable WebDAV Server
Page 134 of 177
Access Data Type Default Value
Get BOOL 0 = False
Set Struct of: UINT32 N/A
(IP address)
UINT32 (Subnet
mask) UINT32
(Gateway)
Get Array of UINT8[3] [0] = 192 [1] =
168 [2] = 0
Get Array of BITS16 0x0000 for each
port
Get Array of CHAR "public"
Get Array of CHAR "private"
Get ENUM 0 (Disabled)
Get Array of UINT8 N/A
Get BOOL 1 = True
Get BOOL 1 = True
Ethernet Host Object (F9h)
Comment
02h: Inactive.
The attribute is set to this value for a
device that only has one physical port.
All two-port functionality is disabled.
No references can be made to this
port.
Note: This functionality is available for
PROFINET, EtherNet/IP and Modbus-
TCP devices.
Enables the option to reset the module from HICP.
Whenever the configuration is assigned or
changed, the Anybus CompactCom module will
update this attribute.
First three bytes in IP address. Used in standalone
shift register mode if the configuration switch
value is set to 1-245. In that case the IP address
will be set to:
Y[0].Y[1].Y[2].X
Where Y0-2 is configured by this attribute and the
last byte X by the configuration switch.
Ethernet PHY configuration bit field. The length
of the array shall equal the number of Ethernet
ports of the product. Each element represents the
configuration of one Ethernet port (element #0
maps to Ethernet port #1, element #1 maps to
Ethernet port #2 and so on).
Note: Only valid for EtherNet/IP and Modbus-TCP
devices.
Bit 0: Auto negotiation fallback duplex
0 = Half duplex
1 = Full duplex
Bit 1– Reserved
15:
Note: This attribute is only valid for PROFINET
devices. Sets the SNMP read-only community
string. Max length is 32.
Note: This attribute is only valid for PROFINET
devices. Sets the SNMP read-write community
string. Max length is 32.
Note: This attribute is currently only valid for
EtherNet/IP devices.
See below (DHCP Option 61, Client Identifier)
Note: This attribute is currently only valid for
EtherNet/IP devices.
See below (DHCP Option 61, Client Identifier)
Note: This attribute is currently valid for
EtherNet/IP and PROFINET devices.
Enable/disable DHCP Client functionality
0: DHCP Client functionality is disabled
1: DHCP Client functionality is enabled
Note: This attribute is currently valid for devices
with IIoT Secure functionality.
Enable/disable WebDAV server
0: WebDAV functionality is disabled
1: WebDAV functionality is enabled
SCM-1202-021 Version 2.6
