Network Specific — PROFINET
Attribute 30-series
#7, Record Data See Comment
Mode
#13, I&M Profile ID Used for all
APIs
#14, I&M Profile Used for all
Specific Type APIs
#15, I&M Version Available
16, I&M Supported Available
#20, Interface Available
description
#21, Module ID Available
Assignment Mode
#22, System Contact Available
#23, PROFIenergy Available
functionality
Command 30-series
Ar_Info_Ind Available
Ar_Offline_Ind Available
Plug_Submodule_Failed Available
Get_IM_Record Available
Set_IM_Record Available
4.3. PROFINET Additional Diagnostic Object (0Fh)
Object removed in the 40-series. All diagnostics are handled via the standard diagnostic object (02h), Event code
FFh. Only Channel diagnostics can be created.
4.4. Diagnostic Object (02h)
The structure of network specific event information has changed in the create command. Instead of including
diagnostic source information such as API, Slot, and Subslot in the data field, it is extracted from the extended
diagnostic fields in the create command. API, Slot, and Subslot are determined with the help of Slot and ADI
given by the extended diagnostic mode.
Process alarms cannot be created in the 40-series.
SCM-1202-021 Version 2.6
40-series Change/Action/Comment
I&M Record data transparent mode (bit 1) is replaced with the IM_Options command in
the Network PROFINET IO object (0Eh).
If this bit is 0 in the current implementation, no action is needed.
Only used for In the 40-series, this attribute is only read for submodules belonging to a "non-zero"
"non-zero" API (e.g. PROFIdrive profile). Constant values (F600h, Generic Device and 0004h,
APIs Communication Module) are used for submodules belonging to API 0.
In the 30-series this parameter is used for all API:s.
Only used for In the 40-series, this attribute is only read for submodules belonging to a "non-zero
"non-zero" API" (e.g. PROFIdrive profile). Constant values (F600h, Generic Device and 0004h,
APIs Communication Module) are used for submodules belonging to API 0.
In the 30-series this parameter is used for all API:s.
Removed Attribute removed in the 40-series. The Anybus CompactCom will never request this
attribute. The host application cannot influence the I&M implemented by the Anybus
CompactCom.
Removed Attribute removed in the 40-series. The Anybus CompactCom will never request this
attribute. The host application cannot influence the I&M supported by the Anybus
CompactCom.
Removed Attribute removed in the 40-series. The Anybus CompactCom will never request this
attribute.
Removed Attribute removed in the 40-series (Incremental Module Identification removed in the
40-series). The Anybus CompactCom will never request this attribute.
Removed Attribute removed in the 40-series. The Anybus CompactCom will never request this
attribute. System Contact can now only be reached from the network via SNMP
(sysContact). Also see
Removed Attribute removed in the 40-series. The Anybus CompactCom will never request this
attribute. PROFIenergy is now enabled by the application having implemented the
Energy Control Object (F0h).
40-series Change/Action/Comment
Removed Command removed in the 40-series. The Anybus CompactCom will never use this command in
a request. The command is replaced by the command Expected_Ident_Ind
Removed Command removed in the 40-series. The Anybus CompactCom will never use this command in
a request. The 30-series module issues this command to indicate to the host application that
the module enters an offline state. Use Ar_Abort_Ind instead.
Removed Command removed in the 40-series. The Anybus CompactCom will never use this command in
a request.
Removed Command removed in the 40-series. The Anybus CompactCom will never use this command in
a request. It will use the general Get_Record-command instead (filter on index AFF0h-AFFFh).
Removed Command removed in the 40-series. The Anybus CompactCom will never use this command in
a request. It will use the general Set_Record-command instead (filter on index AFF0h-AFFh).
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
SNMP MIB-II (page 167).
