Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.7.12. Command Details: AR_Abort_Ind
Category
Extended
Details
Command Code: 19h
Valid For: Object Instance
Description
This command is optional. The module issues this command to indicate to the host application that an
Application Relationship (AR) is aborted (by the application or any other source).
• Command Details
Field Contents
CmdExt[0] AR handle
(low byte)
CmdExt[1] AR handle
(high byte)
MsgData[0] Reason code
(low byte)
MsgData[1] Reason code
(high byte)
Page 128 of 177
Comments
Handle for the Application Relationship (AR)
Reason code for the offline transition
Value: Reason:
0 No reason (unknown reason)
3 Out of memory
4 Add provider or consumer failed
5 Miss (consumer)
6 Cmi timeout
7 Alarm-open failed
8 Alarm-send.cnf(-)
9 Alarm-ack-send.cnf(-)
10 Alarm-data too long
11 Alarm.ind(err)
12 Rpc-client call.cnf(-)
13 Ar-abort.req
14 Re-run aborts existing
15 Got release.ind
16 Device passivated
17
18 Protocol violation
19 NARE error
20 RPC-Bind error
21 RPC-Connect error
22 RPC-Read error
23 RPC-Write error
24 RPC-Control error
25 Forbidden pull or plug after check.rsp and before in-data.ind
26 AP removed
27 Link down
28 Could not register multicast-mac
29 Not synchronized (cannot start companion-ar)
30 Wrong topology (cannot start companion-ar)
31 Dcp, station-name changed
32 Dcp, reset to factory-settings
33 Cannot start companion AR because of parameter error
PROFINET IO Object (F6h)
