Hardware Compatibility
Anybus
CompactCom
40 - PROFINET IRT Transparent
Ethernet
2.3. Brick
The Anybus CompactCom B40-1 does not share dimensions with the Anybus CompactCom B30. The B40-1 is
thus not suitable for migration. However HMS Industrial Networks has developed a separate brick version in
the 40-series, that can be used for migration. This product, B40-2, shares dimensions etc. with the B30. Please
contact HMS Industrial Networks for more information on the Anybus CompactCom B40-2.
Figure H.2. Anybus CompactCom B30
Figure H.3. Anybus CompactCom B40–1 (not for migration)
Figure H.4. Anybus CompactCom B40–2
SCM-1202-021 Version 2.6
Page 159 of 177
