Asset Management Object (E5h)
# Name Access
1 AM info Type Get
2 IM Unique Get
Identifier
3 Location Type Get
4 Location LT Get
5 Location SS Get
6 IM Annotation Get
7 IM Order ID Get
8 IM Serial Get
Number
9 AM Device Get
Identification
10 AM Type Get
Identification
11 AM Software Get
Revision
12 IM Software Get
Revision
SCM-1202-021 Version 2.6
Data Type Default Comment
Value
UINT8 - Asset management data representation
0:
1:
2:
Array of UINT8 0 (unused) 128 bit UUID. Manufacturer created unique defined identifier. Used as source
identification if issuing an event using reporting system or delivering asset
management information.
ISO/IEC 9834-8:2014 specifies the format and generation rules that enable
users to produce 128-bit unique identifiers.
Number of elements in array: 16.
UINT8 - Asset management includes two concepts how to locate an asset. See
section on AM_Location below for more information.
1:
2:
Array of UINT16 - Mandatory if Location Type is "1" (LT). If not present any request will
increase the error counter and the instance will not be reported on the
network. See section on AM_Location below for usage. Maximum number of
elements in array: 12.
struct of - Mandatory if Location Type is "2" (´SS). If not present any request will
increase the error counter and the instance will not be reported on the
UINT16
network. See section on AM_Location below for usage. Maximum number of
BeginSlot
elements in array: 12.
UINT16
BeginSubslot
UINT16 EndSlot
UINT16
EndSubslot
Array of CHAR 64 blanks Manufacturer defined description, The value shall be set to a manufacturer
specific identifier, and can be used for the name of the component.
Maximum number of elements in array: 64.
Array of CHAR 64 blanks Manufacturer defined order id
Maximum number of elements in array: 64.
Array of CHAR 16 blanks Manufacturer defined serial number
Maximum number of elements in array: 16.
Array of UINT16 - The content of this attribute can be used for coding of device, vendor and
organization identification.
See details below.
Number of elements in array: 4.
UINT16 0
0000h
0001h
0002h
0003h
0004h
0005h
0006h
0007h
0100h - 7FFFh
Other
Array of CHAR 64 blanks Manufacturer defined software revision.
Maximum number of elements in array: 64.
Example: "V1.3.0"
If attribute #12, IM Software Revision, is supported, this attribute should not
be implemented.
struct of CHAR V0.0.0 Manufacturer defined software revision.
3*UINT8
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
AM_FullInfo
AM_HardwareOnlyInfo; attributes AM Software Revision and IM Software
Revision are irrelevant
AM_FirmwareOnlyInfo; attributes AM Hardware Revision and IM Hardware
Revision are irrelevant
Twelve level tree format (LT)
Slot- and SubslotNumber format (SS)
Unspecified
PLC
PC based station
IO Module or IO Submodule
Communication Module or Communication Submodule
Interface Module or Interface Submodule
Active Network Infrastructure Component
Media converter
Shall be defined by the manufacturer of the reporting entity
(reserved)
Ethernet
