Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
# Name Access
4 MaxAr Get
5 (Reserved) -
6
7 Record Data Get
Mode
10 I&M Get
Hardware
Revision
11 I&M Get
Software
Revision
12 I&M Get
Revision
Counter
13 I&M Profile Get
ID
14 I&M Profile Get
Specific Type
15-16 (Reserved) -
17 Port 1 MAC Get
address
Page 114 of 177
Data Type Default Value
UINT32 0000 0003h
- -
UINT8 00h
UINT16 Hardware Rev.
Struct of Software Rev.
CHAR
3*UINT8
UINT16 0000h
UINT16 0000h (Non Profile
Device)
UINT16 Generic
Profile: 0004h
(Communication
Module)
- -
Array of -
UINT8
Comment
Max. no.of simultaneous ARs. (Range 1... 4)
Note 1: With S2Enabled = True, MaxAr needs to be at least 2. GSDML
attribute NumberOfDeviceAccessAR must be set to MaxAr - 2.
Note 2: With S2Enabled = False, MaxAr needs to be at least 1. GSDML
attribute NumberOfDeviceAccessAR must be set to MaxAr - 1.
Reserved for future use
This setting affects how Record Data requests are treated, and holds a bit
field as follows:
Bit 0:Index 0... 7FFFh:
0: Normal Mode
1: Transparent Mode
Bit 1:Index AFF0h... AFFFh:
Reserved (replaced with the command IM_Options, see
PROFINET IO Object (0Eh) (page 59))
I&M0 Parameter:
Hardware revision of device; FFFFh indicates availability of profile specific
information
If not implemented, the value of attribute #11 (Hardware version) in the
Application Object (FFh), will be used. If this attribute is not implemented,
the default value will be used.
I&M0 Parameter: Software revision of device.
Byte: Value:
0: "V"
"R"
"P"
"U"
"T"
1: 0... 255
2: 0... 255
3: 0... 255
Please note that version V255.255.255 indicates availability of profile
specific information.
If not implemented, the value of attribute #10 (Firmware version) in the
Application Object (FFh), will be used. If this attribute is not implemented,
the default value will be used.
I&M0 Parameter:
Revision counter of device; a changed value marks a change of the
hardware or its parameters.
I&M0 Parameter:
This attribute is only used for submodules plugged into API > 0.
If the application supports a specific profile, the Profile ID must be defined
here. It shall equal the API number for the profile.
Please note that: this will not change the behavior of the module, since it
does not handle profiles.
I&M0 Parameter:
This attribute is only used for submodules plugged into API > 0.
If the application supports a specific profile, the profile specific type must
be defined here (value is defined by the profile).
Please note: this will not change the behavior of the module, since it does
not handle profiles.
Reserved, not used
6 byte physical address value; overrides the preprogrammed Mac address.
Do not implement this attribute if the preprogrammed Mac address is to
be used.
PROFINET IO Object (F6h)
Network
Meaning:
Official release
Revision
Prototype
Under test
Test Device
Major Version
Minor Version
Internal Change
