Anybus CompactCom 40 - PROFINET IRT Transparent Certification in Generic Anybus Mode
Ethernet
7. Certification in Generic Anybus Mode
In Generic Anybus Mode (when the command API_add in the Network PROFINET IO Object (0Eh) is not used)
there is normally nothing that needs to be considered apart from what is mentioned earlier in this appendix. The
example HMS GSD file has to be modified with respect to the process mapping and identity of the product and
this requires a certification of the product.
Send Map_ADI_Write_Area / Map_ADI_Read_Area
to setup the I/O data to use
Set the product identity information in the
PROFINET IO Object (F6h)
Anybus Object (01h), Instance #1, Setup Complete set to 1
Figure G.1.
