Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.7. PROFINET IO Object (F6h)
11.7.1. Category
Basic, extended
11.7.2. Object Description
This object implements PROFINET IO related settings in the host application.
The implementation of this object is optional; the host application can support none, some, or all of the
attributes specified below. The module will attempt to retrieve the values of these attributes during startup; if
an attribute is not implemented in the host application, simply respond with an error message (06h, "Invalid
CmdExt[0]"). In such a case, the module will use its default value.
If the module attempts to retrieve a value of an attribute not listed below, respond with an error message (06h,
"Invalid CmdExt[0]").
See also...
• Network PROFINET IO Object (0Eh) (page 59)
• Flowchart — Record Data Access (page 139)
• Anybus CompactCom 40 Software Design Guide, "Error Codes"
11.7.3. Supported Commands
Object: Get_Attribute (01h)
Get_Record (10h, see below)
Set_Record (11h, see below)
AR_Check_Ind (14h, see below)
Cfg_Mismatch_Ind (15h, see below)
Expected_Ident_Ind (1Bh, see below)
End_Of_Prm_Ind (17h, see below)
AR_Abort_Ind (19h, see below)
Indicate_Device (1Eh, see below)
Prm_Begin_Ind (1Fh, see below)
Instance: Get_Attribute (01h)
11.7.4. Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
Page 112 of 177
Access Data Type Value
Get Array of CHAR "PROFINET IO"
Get UINT8 02h
Get UINT16 0001h
Get UINT16 0001h
PROFINET IO Object (F6h)
