Energy Control Object (F0h)
11.6.3. Supported Commands
Object: Get_Attribute
StartPause
EndPause
Preview_Pause_Time (not PROFINET)
Instance: Get_Attribute
11.6.4. Object Attributes (Instance #0)
# Name
1 Name
2 Revision
3 Number of instances
4 Highest instance no.
11 Current Energy Saving
Mode
12 Remaining time to
destination
13 Energy consumption to
destination
14 Transition to "Power off"
mode supported
SCM-1202-021 Version 2.6
Access Data Type Value
Get Array of CHAR "Energy Control"
Get UINT8 02h
Get UINT16 -
Get UINT16 Highest created instance number. Maximum value is 8.
Get UINT16 Instance number of the currently used Energy saving mode. During
a mode transition the new Energy saving mode shall be presented.
"Ready to operate" will equal instance #1, and "Power off" mode will
equal Highest instance number.
Get UINT32 When changing mode this parameter will reflect the actual time (in
milliseconds) remaining until the shift is completed.
If a dynamic value cannot be generated the static value for the
transition from the source to destination mode shall be used.
If the value is infinite, or unknown, the maximum value 0xFFFFFFFF
shall be used.
Get FLOAT When changing mode this parameter will reflect the actual energy (in
kWh) which will be consumed until the shift is completed.
If a dynamic value cannot be generated the static value for the
transition from the source to destination mode shall be used.
If the value is undefined the value 0.0 shall be used.
Get BOOL Indicates whether transition to "Power off" mode is supported or not.
0:
1:
® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Not supported
Supported
