Diagnostic Object (02h)
10.3. Diagnostic Object (02h)
10.3.1. Category
Extended
10.3.2. Object Description
This object provides a standardized way of handling host application events & diagnostics, and is thoroughly
described in the general Anybus CompactCom 40 Software Design Guide.
10.3.3. Supported Commands
Object: Get_Attribute
Create
Delete
Instance: Get_Attribute
10.3.4. Object Attributes (Instance #0)
# Name
1... 4 -
11 Max no. of instances
12 Supported functionality
10.3.5. Instance Attributes (Instance #1)
Extended
# Name
1 Severity
2 Event Code
3 NW specific data
4 Slot
5 ADI
6 Element
7 Bit
SCM-1202-021 Version 2.6
Access Data Type Value
- - Consult the general Anybus CompactCom 40 Software Design Guide for
further information.
Get UINT16 5+1 (Of the maximum number of instances there should always be one
instance reserved for an event of severity level 'Major, unrecoverable',
to force the module into the 'EXCEPTION'-state.)
Get BITS32 Bit 0: "0" (Latching events are not supported)
Bit 1 - 31: reserved (shall be "0" )
Access Data Type Value
Get UINT8 Consult the general Anybus CompactCom 40 Software Design Guide for
further information.
Get UINT8
Get Array of UINT8 Optional network specific information, see below.
Get UINT16 Consult the general Anybus CompactCom 40 Software Design Guide for
further information.
Get UINT16
Get UINT8
Get UINT8
® ™
