Network Specific — PROFINET
4.8. LED Indications
Changes has been made regarding the specification of the LED indications. See tables below for differences.
3
1
Figure H.6.
Network Status LED (LED1[A..B])
LED State 30-series
Off Offline
Green Online (RUN)
Green, 1 flash -
Green, cont. flash -
Online (STOP)
Red Fatal event
Red, 1 flash -
Red, 2 flashes -
Red, 3 flashes -
Module Status LED (LED2[A..B])
LED State 30-series
Off Not Initialized
Green Normal Operation
Green, 1 flash Diagnostic Event
Green, cont. flash Identify
Red Exception error
Fatal Event
Red, 1 flash Configuration error
Red, 2 flashes IP address error
Red, 3 flashes Station Name Error
Red, 4 flashes Internal error
Alternating Red/ -
Green
4.9. SNMP MIB-II
sysContact, sysLocation and sysName are used to give the product identification in the end installation.
In the 40-module these variables are only set from the network using SNMP protocol by the end user.
Due to this, sysContact (PROFINET IO object (F6h), Attribute 22), sysLocation (Network Configuration Object
(04h), Attribute 17) and sysName (Network Configuration Object (04h), Attribute 15) are no longer used.
SCM-1202-021 Version 2.6
4
2
40-series Comments
Offline - No power- No connection with IO controller
Online (RUN) Connection with IO controller established, IO controller in Run state
Online (STOP) Connection with IO controller established, IO controller in STOP state or IO data
bad, IRT synchronization not finished
Identify Flashing continuously to identify slave (DCP_Identify).
- Connection with IO controller established, IO controller in STOP state
Fatal event Major internal error (this indication is combined with a red module status LED)
Station Name error Station name not set
IP address error IP address not set
Configuration error Expected Identification differs from Real Identification.
40-series Comments
Not Initialized No power or Module in SETUP or NW_INIT state
Normal Operation Module has shifted from the NW_INIT state
Diagnostic Event Diagnostic event(s) present
- Flashing 1Hz continuously to identify slave (DCP_Identify).
Exception error Module in state Exception
Fatal Event Major internal error (this indication is combined with a red Network Status LED)
-
-
-
-
Firmware Update Do NOT power off the module. Turning the module off during this phase could
cause permanent damage.
® ™
