Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
Custom Configuration (Advanced Users)
Optionally it is possible to override the default configuration during the SETUP state by means of the PROFINET
specific commands API_add, Plug_Module, Plug_Submodule, and Plug_Submodule_Ext. This way, the host
application can define exactly how ADIs are represented on PROFINET by defining custom modules and
submodules. These commands need to be sent after the process data is mapped, and before sending setup
complete to the Anybus CompactCom 40 PROFINET IRT.
See also...
• Network PROFINET IO Object (0Eh) (page 59)
• Flowchart —Establishment of Real Identification (RI) (page 141)
