Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
10.2. Anybus Object (01h)
10.2.1. Category
Basic
10.2.2. Object Description
This object assembles all common Anybus data, and is described thoroughly in the general Anybus CompactCom
40 Software Design Guide.
IMPORTANT
Instance attribute #16 has to be set to 0002h during SETUP state to enable Transparent Ethernet
functionality.
10.2.3. Supported Commands
Object: Get_Attribute
Reset
Instance: Get_Attribute
Set_Attribute
Get_Enum_String
10.2.4. Object Attributes (Instance #0)
(Consult the general Anybus CompactCom 40 Software Design Guide for further information.)
10.2.5. Instance Attributes (Instance #1)
Basic
# Name
1 Module type
2... 11 -
12 LED colors
13... 15 -
16 GPIO configuration
17 Virtual attributes
18 Black list/White list
19 Network time
Page 40 of 177
Access Type Value
Get UINT16 0403h (Standard Anybus CompactCom 40)
- - Consult the general Anybus CompactCom 40 Software Design Guide for
further information.
Get struct of: Value: Color:
UINT8 (LED1A) 01h Green
UINT8 (LED1B) 02h Red
UINT8 (LED2A) 01h Green
UINT8 (LED2B) 02h Red
- - Consult the general Anybus CompactCom 40 Software Design Guide for
further information.
Get/Set UINT16 Configuration of the host interface GIO pins. To enable Transparent
Ethernet, this attribute has to be set to 0002h during SETUP state.
Get/Set - Consult the general Anybus CompactCom 40 Software Design Guide for
further information.
Get/Set
Get UINT64 0 (Not supported)
Anybus Object (01h)
SCM-1202-021 Version 2.6
