Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
11.6.5. Instance Attributes (Instance #1 - #8)
# Name
1 ModeAttributes
2 TimeMinPause
3 TimeToPause
4 TimeToOperate
5 TimeMinLengthOfStay
6 TimeMaxLengthOfStay
7 ModePowerConsumption
8 EnergyConsumptionToPau
se
9 EnergyConsumptionToOpe
rate
10 Availability
11 Power Consumption
Page 108 of 177
Access Data Type Description
Get BITS16
Bit 0:
0:
1:
Bit 1-15:
Get UINT32 Minimum pause time in milliseconds. (t
If the value is infinite, or unknown, the maximum value 0xFFFFFFFF
shall be used.
Get UINT32 Maximum time to go to this Energy saving mode.(ms, t
If the value is infinite, or unknown, the maximum value 0xFFFFFFFF
shall be used.
Get UINT32 Maximum time needed to go to the "Ready to operate" mode. (ms, t
If the value is infinite, or unknown, the maximum value 0xFFFFFFFF
shall be used.
Get UINT32 The minimum time that the device must stay in this mode. In
milliseconds.(ms, t
If the value is infinite, or unknown, the maximum value 0xFFFFFFFF
shall be used.
Get UINT32 Maximum time that is allowed to stay in this mode. In milliseconds.
If no maximum value is available or if not implemented, the maximum
value FFFFFFFFh shall be used.
Get FLOAT Amount of power consumed in this mode. (kW)
If the value is undefined the value 0.0 shall be used.
Get FLOAT Amount of energy required to go to this mode. (kWh)
If the value is undefined the value 0.0 shall be used.
Get FLOAT Amount of energy required to go to the "Ready to operate" mode from
this mode. (kWh)
If the value is undefined the value 0.0 shall be used.
Get BOOL Indicates if this energy saving mode is available given the current device
state.
Not used for PROFINET.
False
True
Get UINT32 Indicates the power consumption of the device when in this state.
Not used for PROFINET.
Energy Control Object (F0h)
Meaning:
Only static time and energy values are available (Value of bit 0 attribute is
not implemented)
Dynamic time and energy values are available
Reserved
)
pause
)
off_min
Not available
Available (Value if attribute not implemented)
SCM-1202-021 Version 2.6
)
off
)
on
