Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
4.5. Network Configuration Object (04h)
The instances in the Network Configuration Object have been rearranged for the Ethernet based modules for
consistency. Network specific instances are moved to instance number 20 and onwards. This is done to increase
the number of instances in the section that are not network specific.
If the host application is using any of the parameters below, the software must be updated to use the new
instance numbers.
Parameter Name
DNS1
DNS2
Host Name
Domain Name
SMTP Server
SMTP User
SMTP Password
Station Name
F-Address
Function Tag
Location Tag
Installation Date
Description
4.6. Network PROFINET IO Object (0Eh)
Attribute 30-series
#3, Last OffLineInd -
ReasonCode
#9, ProfinetIoStack Init -
ErrorCode
4.7. I&M4
I&M4 is removed in the 40-series. Writeable I&M records in GSD must be updated (see GSD section below).
Page 166 of 177
30-series Instance #
8
9
10
11
12
13
14
15
20
16
17
18
19
40-series Change/Action/Comment
Removed Attribute removed in the 40-series. Since the command Ar_Offline_Ind is removed, this
attribute makes no sense.
If the host application is accessing this attribute, it will receive an error response when using
the 40-series.
Removed Attribute removed in the 40-series.
If the host application is accessing this attribute, it will receive an error response when using
the 40-series.
Network Specific — PROFINET
40-series Instance #
9
10
11
12
13
14
15
20
21
Parameter removed
Parameter removed
Parameter removed
Parameter removed
