HMS Networks Anybus CompactCom 40 Network Manual page 96

® ™
Anybus CompactCom 40 - PROFINET IRT Transparent
Ethernet
Attr ID# Access Rule Name
10 Get Current
11 Get Min Current
12 Get Max Current
Page 88 of 177
Data Type Element number:description
UINT64 6: L3-G TS
FLOAT 7: L3-G Value
UINT32 8: Reserved
UINT64 9: Avg L-G TS
FLOAT 10: Avg L-G Value
UINT32 11: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Avg L TS
FLOAT 10: Avg L Value
UINT32 11: Reserved
UINT64 12: N TS
FLOAT 13: N Value
UINT32 14: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Avg L TS
FLOAT 10: Avg L Value
UINT32 11: Reserved
UINT64 12: N TS
FLOAT 13: N Value
UINT32 14: Reserved
UINT64 0: L1 TS
FLOAT 1: L1 Value
UINT32 2: Reserved
UINT64 3: L2 TS
FLOAT 4: L2 Value
UINT32 5: Reserved
UINT64 6: L3 TS
FLOAT 7: L3 Value
UINT32 8: Reserved
UINT64 9: Avg L TS
FLOAT 10: Avg L Value
UINT32 11: Reserved
UINT64 12: N TS
FLOAT 13: N Value
UINT32 14: Reserved
Energy Measurement Object (E4h)
PROFIenergy Measurement ID
7
8
9
33
-
76
77
78
94
-
46
47
48
64
-
SCM-1202-021 Version 2.6
