PROFINET IO Object (F6h)
11.7.11. Command Details: End_Of_Prm_Ind
Category
Extended
Details
Command Code: 17h
Valid For: Object Instance
Description
The module may issue this command to indicate to the host application that the parameterization phase is
completed. It is optional to implement support for this command.
If implemented, the host application may, depending on the response issued to this command, be required to
issue 'Appl_State_Ready' at a later stage to indicate that it is ready for data exchange. If not implemented, this is
handled automatically by the module.
• Command Details
Field Contents
CmdExt[0] AR handle (low byte)
CmdExt[1] AR handle (high byte)
MsgData[0] API (low word, low byte)
MsgData[1] API (low word, high byte)
MsgData[2] API (high word, low byte)
MsgData[3] API (high word, high byte)
MsgData[4] Slot (low byte)
MsgData[5] Slot (high byte)
MsgData[6] Subslot (low byte)
MsgData[7] Subslot (high byte)
• Response Details
Field Contents
CmdExt[0] (reserved)
CmdExt[1]
MsgData[0] Subslot (high byte)
See also...
• Appl_State_Ready, details in
SCM-1202-021 Version 2.6
Comments
Handle for Application Relationship (AR)
Application Process Instance (API) - Only valid if subslot > 0
Slot number affected by the command - Only valid if subslot > 0
Subslot number affected by the command
Value: Meaning:
0: Command applies to all modules in the configuration
other: Command applies only to the specified slot/subslot
Comments
(set to zero)
Value: Meaning:
0: Ready for Data Exchange
1: Not ready for data exchange (Appl_State_Ready must be issued at a later stage)
Network PROFINET IO Object (0Eh) (page 59)
® ™
